Product Description

Evolution MD255SEG-CS Segmented Edge Heavy Duty Diamond Demolition Disc Cutter Blade 255mm x 22.2mm x 16T

The Evolution MD255SEG-CS Segmented Edge Heavy Duty Diamond Demolition Disc Cutter Blade is designed for use with the R255DCT Concrete Cutting Saw. It offers multi-purpose cutting capabilities, allowing you to cut various building materials such as metals, bricks, tiles, and plastics, thus saving time and money. With up to 30 times longer blade life compared to abrasive discs when cutting metal, it boasts superior durability. The steel blade body with a diamond cutting edge maintains its full diameter for maximum cutting capacity throughout its lifetime. Safety is enhanced as the steel body doesn't shatter like abrasives, reducing the risk of injury, while fewer dust, sparks, and odors make for a cleaner and safer cutting experience. Cooling holes near the edge help dissipate heat, ensuring optimum cutting performance. The segmented rim design with sub-segmented cutting edges improves efficiency and debris removal from the cut. With a diameter of 255mm, a maximum speed of 6150 RPM, and 16 teeth, this blade is a robust and efficient cutting solution for heavy-duty applications. We do not recommend using Evolution blades on other branded machines, as due to the multi purpose technology of Evolution's machines, the RMP is reduced.

MD255SEG-CS Features:

• Compatible with the R255DCT Concrete Cutting Saw
• Multi-purpose Cutting: One saw & One blade will cut most common building materials including ferrous & non-ferrous metals, bricks, tiles, plastics & more saving you time and money.
• 30x Longer Life: Up to 30x longer blade life than abrasive discs when cutting metal. Diamond cutting edge is incredibly tough and can make over 1,000 cuts through steel.
• Constant Diameter: Steel blade body with diamond cutting edge maintains its full diameter so you have maximum cutting capacity for the lifetime of the blade.
• Cleaner & Safer: The steel body won’t shatter, unlike abrasives, which can cause serious injury. Less dust, less sparks & less odour vs abrasive discs, make this a safer cutting solution.
• Cooling holes close to the edge expel heat to maintain optimum cutting performance.
• Heavily concentrated diamonds give a coarser cutting edge compared to standard diamond blades.
• Superior quality diamonds for longer blade life.
• Segmented rim design with sub-segmented cutting edge improves efficiency & removes debris from the cut.
• Thick body plate strengthens the blade for stability and accuracy.

MD255SEG-CS Specification:

• Dia. Ø: 255mm
• Max. Speed: 6150 RPM
• Bore / Arbor Ø: 22.2mm
• Rim: Segmented
• Base Thickness: 1.8mm
• Segment / Tooth Thickness: 3.1mm
• Segment / Tooth Height: 3mm
• Segment / Tooth Quantity: 16
• Sub-Segment / Tooth Quantity: 80

What is included:

• 1x MD255SEG-CS Disc Cutter Blade 255mm x 22.2mm x 16T
